CZI GL10 Gimbal Spotlight for DJI Mavic 3E/3T

CZI GL10 Gimbal Spotlight for DJI Mavic 3E/3T: Illuminate Your Missions

The CZI GL10 Gimbal Spotlight is a powerful and versatile lighting solution designed specifically for the DJI Mavic 3E and 3T drones. Equipped with dual spotlights, integrated red/blue warning LEDs, and advanced gimbal stabilization, the GL10 is ideal for night patrols, search and rescue, and other demanding applications.

Key Features:

• Dual Spotlights & Warning LEDs: Features dual spotlights for powerful illumination and integrated red/blue warning LEDs for enhanced visibility and public safety operations.
• High-Powered Illumination: 30W rated power delivers a sharp beam with a 12.5-degree angle, providing an effective search distance of 100 meters. Uniform brightness and high color consistency ensure clear visibility.
• Dual-Axis Gimbal Stabilization: Advanced dual-axis gimbal stabilization technology enables precise rotation and pitch movement, enhancing stability and reducing shake.
• AI-Powered Light Centering: Integrated AI algorithms automatically center the light spot and adjust the beam pattern based on the gimbal angle.
• Lightweight and Integrated Design: Compact and lightweight design with a unique quick-release mechanism for easy installation and removal.

Specifications:

• Compatibility: DJI Mavic 3E / 3T
• Electrical Interface: DJI PSDK
• Weight: 130g ± 4%
• Dimensions: 107 x 128 x 51.5mm
• Total Power: 30W
• White LED Power: 20W
• Red & Blue LED Power: 2W
• Supply Voltage: 15V
• Luminous Flux: 1830lm ± 3%
• Field of View (FOV): 12.5 degrees
• Search Distance & Illumination:
  • 100m: Spot diameter 22.8m, search area 407 sq meters, center illumination 5.8Lux
  • 75m: Spot diameter 17.1m, search area 229 sq meters, center illumination 13.3Lux
  • 50m: Spot diameter 11.4m, search area 102 sq meters, center illumination 22.8Lux
• Functions: White light, red/blue flash, dual-axis gimbal stabilization, AI-powered light centering
• Gimbal Control Range: Pitch -90° to +70°
• Operating Temperature: -20°C to 50°C

Ideal for:

• Nighttime patrols
• Search and rescue operations
• Direction indication
• Inspections
• And other demanding applications requiring powerful and precise illumination.
